This series allows multiple injection possibilities according to the head chosen. The available heads are from 330 to 1200 l/h for the piston series, and from 207 to 1080 l/h for the diaphragm series.

DOSTEC 50 dosing pumps are made of materials resistant to most of the liquid products used in processes where a product has to be dosed into a hydraulic network such as: food industry, textile, chemical, water treatment, agriculture, etc. (See materials in Technical Characteristics). In case of doubts about the compatibility of the materials with the products to be used, please contact ITC S.L. Technical Service.

The dosing flow rate is adjustable without stopping the pump, from 0% to 100% of its capacity.

Piston:

Flow ratePressure

50Hz60Hz

l/h GPHl/hGPHbar PSI

330 8740010612 174

Materials:

- Cylinder: P.P / AISI 316 / PVDF / PTFE

- Diaphragm: PTFE in fiber reinforced elastomer base

- Piston: Ceramic / PEUHMW

- Sealing: FPM

- Valve (body): P.P / AISI 316 / PVDF / PTFE

- Valve (ball): Glass / Borosilicate glass / Ceramic

- Block: Cast aluminum
