Pylontech 3kW 5.6kWh 24Vdc lithium battery isolated self-consumption kit

It is a system to power consumption of an occasional home, weekend or summer, with a low power consumption, which will allow us very interesting extensions to have total self-sufficiency in an isolated installation or also with connection to the grid only as a backup. Thanks to our kits, you will be able to assemble your own installation easily and safely. We will deliver the inverter, battery and connection panel pre-wired and mounted on a board, ready to hang and connect. We will leave all the equipment duly configured from the factory so that there is no need to program or configure anything. Just buy, connect and enjoy. The solar panels will be connected by means of cables with approved connectors called MC4 and we will also provide you with a scheme of how to connect the panels for each case.

4 SOLAR PANELS JA 450W MONOCRYSTALLINE 144C SILVER FRANE HALF CUT OR AN ALTERNATIVE AND SIMILAR CHARACTERISTICS

TECHNICAL CHARACTERISTICS (31-016465)

1 INVERTER CHARGER AXPERT VM III 24V 3000VA MPPT 50 (020018)

2 PYLONTECH UP2500 24V 2.8KWH LITHIUM BATTERIES (070005)

1 BATTERY CONNECTION KIT CABLE (PYLONTECH) (050004)

1 KIT SMALL ISOLATED INSTALLATION EQUIPMENT 3kW

• 2 units of fuse and fuse holder. 2
• units of 2p 16A circuit breaker. 1
• Schuko 16A plug. 1
• IP65 watertight box for 6 modules. 2
• units galvanized iron bracket.

2 KIT COPLANAR STRUCTURE FOR TILE L FEET 2 PANELS IN VERTICAL (03002T).

For the installation of this KIT, it will be necessary the following material not included, since it will depend on the necessity of each installation and that it will be able to acquire separately in our web page or in any electrical store:

• MC4 connectors
• Solar cable 1x4 mm Black.
• Solar cable 1x4 mm Red.
• RV-K cable 3G4mm.

• All connections are MC4 clip type and male-female, where it is impossible to get confused.
• Just remember to connect the red cable that we deliver to the male connector on the board
• The electrical panel provided will also have the corresponding MC4 connectors so that it is impossible to get confused with the polarity, because they are male-female and do not allow any other connection than the correct one.
• The AC power can be taken from a connector with push-in terminals, properly labeled, very safe so that you only need to press and insert the bare wire through the hole in the terminal, without a screwdriver or tools!
• There will also be in the box a plug base simply to plug in what you need, even easier.
• All our equipments are perfectly expandable a posteriori, if the need of the installation changes over time, both in solar panels (generation) and batteries (storage) *only in lithium.
• The only thing that cannot be extended is the power of the inverter.
• If required, we can provide an installer for the assembly of the installation.
• You can consult us for the installation fee.

The kits that we provide, have been widely installed by us, this kit of isolated self-consumption M is recommended for:

• Small house occasional use
• In addition to the commented material, we attach the electrical accessories that you can visualize in this same page to be able to make the different connections between the equipment and also the supports to place the batteries in the form of a tower

Plug in and enjoy, now anyone can save energy. If you have doubts or have never done it. We help you! because this is the future and nobody can stop it.
